This platform is based on the latest “Merlin Falcon” AMD Embedded R-Series SOC designed for high level graphic performance. It includes 3 independent heads with UltraHD 4K resolution and h.264/h.265 4K hardware decoding, along with hardware features to comply with GLI11 certification, and implements a Boot Security Chain to improve security and guarantee easier security tests and audits.

Specifications

CPU/GPU

“Merlin Falcon” AMD Embedded R-Series Quad Core SOC with integrated
AMD Radeon GPU
Support for 3 independent 4K displays
H.264 hardware decoding on 4K resolution
H.265 hardware decoding on 4K resolution
Security

PSP, HWB, DRM, TPM 1.2
System Memory

2x SO-DIMM up to 32GB DDR4
Bios

Custom BIOS with Boot Security Chain on socket
Custom storage

SRAM with battery backup on 64-bit parallel interface
FRAM non-volatile memory on 64-bit parallel interface (alternative to SRAM)
Serial FRAM non-volatile memory on SPI bus
1x DIP-8 socket on I2C bus for jurisdiction chip
Video output

3x DisplayPort 4K
2x optional video outputs
Audio

5.1 Jack non-amplified
S/PDIF
Line-in + Mic
External ports

2x USB 3.0 + 2x USB 2.0
2x LAN
4x RS-232 Full Modem DB9
2x CCTalk
64 GPIOs (32xIN + 32xOUT)
iButton® interface
Internal storage & ports

2x SATA data & power connector
2x CFAST
1x M.2 connector
1x SD
2x USB 3.0 + 2x USB 2.0
2x RS-232 Full Modem
Security switches

2x Internal Security Switch for board opening detection
6x External Security Switches
Power connector

Mini-Fit 2x4p
Operating voltage

12V
Operating systems

Windows, WeS, Linux
