G660 Cayenne - PSM TECH

G660 è una piattaforma AWP completa basata sulla CPU Intel® Bay-Trail dual Core, che si distingue per le sue elevate prestazioni di elaborazione e grafica grazie alla GPU integrata HD Graphics 4000, con supporto hardware per OpenGL 4.0 e H.264. È una soluzione entry-level ed economica, progettata per un consumo energetico ultra ridotto.

Specifications

CPU

Intel® Bay Trail N2807 with 22nm technology
CPU Dual-core up to 2.16GHz

Graphics

HD Graphics 4000
Dual High Resolution independent Displays
HW Support of DirectX 11, OpenGL 4.0 OpenCL 1.2,
H.264, MPEG2, MVC, VC-1, VP8, MJPEG

Video outputs

VGA up to 2560×1600@60Hz
DVI-D up to 1920×1080@60Hz

System memory

Up to 4GB DDR3L 1333MHz soldered onboard

Mass storage

eMMC 8GB
SATA3 port with housing for SSD 2.5″ or SATA DOM

Custom memory

Paralel SRAM 2MB with battery backup
Serial FRAM 8kB NVRAM

Jamma

28+28 pin
Amplified Audio Output 2x20W
Dual RS-232 auxiliary
2 Aux Tamper Monitor inputs
3-state Output for electromechanical locks

External ports

3 x USB 2.0
CCTalk for Hopper and Coin Acceptor
3 x RS-232 port on DB9
Gigabit Ethernet

Removable Mass Storage

μSD reader
Socket EEPROM (internal)

Security

Board opening detection with timestamp (battery backup)
Unique Serial Number
Hardware Protection with cypher key
Software check for Voltage and Temperatures
TPM 1.2 (optional)
